The Single Plate MICROVAP (Cat#11801) is our most compact evaporator, making it ideal for laboratories with limited bench or hood space. It provides an affordable solution to dry down high capacity, low volume samples in a 96 well microplate.
| Single Plate MICROVAP Specifications | ||
| Heater Type | Dry Block | None |
| Instrument Catalog Number | 11801 | 11801-O |
| Number of Sample Plates | 1 | 1 |
| Overall Dimensions (W x D x H) |
10 x 12.5 x 17 in 25.4 x 31.75 x 43.18 cm |
8.5 x 13 x 14.5 in 21.6 x 33 x 35.6 cm |
| Microplate Dimensions (W x D) | 3.375 x 5 in 8.5 x 13 cm |
3.375 x 5 in 8.5 x 13 cm |
| Gas Manifold Layout | 8 x 12 Array | 9 x 12 Array |
| Center to Center Spacing Between Positions | 0.354 in 9 mm |
0.354 in 9 mm |
| Gas Flow Meter | 0-25 LPM | 0-25 LPM |
| Stainless Steel Needles Length and Gauge | 2.0 in x 19 ga 51 mm x 19 ga |
2.0 in x 19 ga 51 mm x 19 ga |
| Hoist Assembly | Manual | Manual |
| Standard Gas Input Range | 20-30 psi | 20-30 psi |
| Heating Device Specifications | ||
| Model Number | 18103 | N/A |
| Outside Dimensions (W x D x H) |
10 x 9.75 x 3.5 in 25.4 x 24.8 x 8.9 cm |
N/A |
| Total Wattage | 180 W | N/A |
| Temperature Range | 40-130 °C | Ambient |
| Temperature Controller Type and Controller Accuracy |
Digital +/- 2°C |
N/A |
