80 Position MULTIVAP Nitrogen Evaporator

The 80 Position MULTIVAP (Catalog# 11880) is a high temperature dry block unit, designed for large batches of small volume samples. It can accommodate a sample tube size anywhere from 10 to 17 mm OD.

Part Number N/A Categories , , , Brands

Add to cart to Request a Quote.

80 Position MULTIVAP Specifications
Heater Type Dry Block
Instrument Catalog Number 11880
Number of Sample Plates 80
Overall Dimensions
(W x D x H)
15.25 x 14 x 22 in
39 x 36 x 56 cm
Test Tube Diameter 10-17 mm OD
Center to Center Spacing Between Positions 0.8 in
2.03 cm
Gas Manifold Layout 8 x 10 Array
Gas Flow Meter 0-25 LPM
Stainless Steel Needles Length and Gauge 4.0 in x 19ga
102 mm x 19ga
Hoist Assembly Dual Pulley and Band Springs
Standard Gas Input Range 30-110 psi



Heating Device Specifications
Model Number 9156
Outside Dimensions
(W x D x H)
15.25 x 14 x 6.5 in
39 x 36 x 15 cm
Total Wattage 900 W
Temperature Range 30-120 °C
Temperature Controller Type and
Controller Accuracy
Digital
+/- 2°C
