| Model | Smart N 15UV | Smart N 15VF | Smart N 30UV | Smart N 30VF |
| Feed Water Requirement | ||||
| Source | Tap water | Tap water | Tap water | Tap water |
| Conductivity* | <2000us/cm | <2000us/cm | <2000us/cm | <2000us/cm |
| Hardness ** | <450ppm as CaCO3 | <450ppm as CaCO3 | <450ppm as CaCO3 | <450ppm as CaCO3 |
| Pressure | 0.05~0.5MPa(7-72psi) | 0.05~0.5MPa(7-72psi) | 0.05~0.5MPa(7-72psi) | 0.05~0.5MPa(7-72psi) |
| Temperature | 5~40℃ | 5~40℃ | 5~40℃ | 5~40℃ |
| Purification Water(Class III) | ||||
| lonic Rejection | >95 | >95% | >95% | >95% |
| Bacteria Rejection | >99% | >99% | >99% | >99% |
| Conductivity | 1~20us/cm | 1~20us/cm | 1~20us/cm | 1~20us/cm |
| Productivity Rate | 15L/h | 15L/h | 15L/h | 15L/h |
| Ultrapurification Water(Class I) | ||||
| Resistivity At 25 C | 18.2ΜΩ.cm | 18.2ΜΩ.cm | 18.2ΜΩ.cm | 18.2ΜΩ.cm |
| Conductivity At 25C | 0.055us/cm | 0.055us/cm | 0.055us/cm | 0.055us/cm |
| TOC Level *** | 1~5ppb | 1~5ppb | 1~5ppb | 1~5ppb |
| Endotoxin(Pyrogens) **** | N/A | <0.001EU/ml | N/A | <0.001EU/ml |
| Particulate(≥0.02um) | <1pc/ml | <1pc/ml | <1pc/ml | <1pc/ml |
| Bacteria *** | <0.1cfu/ml | <0.1cfu/ml | <0.1cfu/ml | <0.1cfu/ml |
| Rnase / Dnase ** | N/A | Free | N/A | Free |
| Manual dispense flow rate | 1.5~2.0L/min | 1.5~2.0L/min | 1.5~2.0L/min | 1.5~2.0L/min |
| Automatic dispense volume | 100~60000ml | 100~60000ml | 100~60000ml | 100~60000ml |
| Electrical Requirements | ||||
| Electrical Voltage | 110V/220V±10% | 110V/220V±10% | 110V/220V±10% | 110V/220V±10% |
| Electrical Frequency | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ | 50HZ/60HZ |
| Packing Information | ||||
| Net Weight | ||||
| Main units | 24kg | 24kg | 24kg | 24kg |
| Water tank (30L) | 7kg | 7kg | 7kg | 7kg |
| External Dimensions(WxDxH) | ||||
| Main units | 315×525×570mm | 315×525×570mm | 315×525×570mm | 315×525×570mm |
| Water tank (30L) | 380×380×595mm | 380×380×595mm | 380×380×595mm | 380×380×595mm |
| Shipping weight | ||||
| Main units | 37kg | 37kg | 37kg | 37kg |
| Water tank (30L) | 15kg | 15kg | 15kg | 15kg |
| Shipping Dimensions(WxDxH) | ||||
| Main units | 525×610×770mm | 525×610×770mm | 525×610×770mm | 525×610×770mm |
| Water tank (30L) | 520×440×615mm | 520×440×615mm | 520×440×615mm | 520×440×615mm |
| Configuration | ||||
| Pretreatment module | ✓ | ✓ | ✓ | ✓ |
| High pressure pump | ✓ | ✓ | ✓ | ✓ |
| Reverse osmosis | ✓ | ✓ | ✓ | ✓ |
| Dual wavelength UV-lamp | ✓ | ✓ | ✓ | ✓ |
| Ultra-purification cartridge | ✓ | ✓ | ✓ | ✓ |
| Microfiltration cartridge | ✓ | – | ✓ | – |
| Ultrafiltration cartridge | – | ✓ | – | ✓ |
| Point-of-use filter | ✓ | ✓ | ✓ | ✓ |
| Storage tank 30L | ✓ | ✓ | ✓ | ✓ |
| Air filter net for tank | ✓ | ✓ | ✓ | ✓ |
| Remote water dispenser | ✓ | ✓ | ✓ | ✓ |
